NTN R10LLB01 Single Row Deep Groove Radial Ball Bearing, 15.875 mm Bore x 34.925 mm OD x 8.73 mm W, Double Seal, Pressed Steel Cage
- MFR #:R10LLBC3/EM
- EIS #:R10LLB01
- Series #:R10
- UPC #:04547359495874
- MFR #:R10LLBC3/EM
- EIS #:R10LLB01
- Series #:R10
- UPC #:04547359495874
In Stock | Ready to Ship
Min Qty:1
|Qty Increment:1
NTN R Seriesnbsp;single row deep groove radial ball bearing.
NTN R Series Single Row deep groove radial ball bearing, 9.525 mm bore, stainless steel cage material, clearance: c3, 3300 n dynamic load capacity, 0.406 mm fillet radius, 1 row, 22.225 mm outside diameter, 31000 rpm limiting (grease) speed rating, 1400 n static load capacity, temperature rating: -40 to 120 deg c, 7.142 mm width.$19.30 / Piece
Min Qty:1
|Qty Increment:1
NTN R Seriesnbsp;single row deep groove radial ball bearing.
NTN R Series Single Row deep groove radial ball bearing, 9.525 mm bore, stainless steel cage material, clearance: c3, 3300 n dynamic load capacity, 0.406 mm fillet radius, 1 row, 22.225 mm outside diameter, 31000 rpm limiting (grease) speed rating, 1400 n static load capacity, temperature rating: -40 to 120 deg c, 7.142 mm width.- Attributes
- Features
Attributes
General Information
Item NameDeep Groove Radial Ball Bearing
SeriesR10
General Features
TypeMiniature/Extra Small, Round Bore
Design & Construction
Cage MaterialPressed Steel
Enclosure TypeDouble Non-Contact Seal
Seal MaterialNitrile Butadiene Rubber
Performance Details
Dynamic Load Capacity4600 N
Static Load Capacity2910 N
Physical Properties
Bore Diameter15.875 mm
Fillet Radius0.787 mm
Number of Rows1
Outside Diameter34.925 mm
Width8.73 mm
Features
- Clearance: C3
- Temperature Rating: -40 to 120 °C
