ACL Staticide ACL Staticide DualMat Dual Layer ESD Table Mat, 30 inch x 40 ft, 0.08 inch, Dark Gray, Roll

ACL Staticide-Table Mats-ACL8385DGYR2440;ACL8385DGYM3060;ACL8385DGYM2460;ACL8385DGYM2436;ACL8385DGY3040;ACL8285RBR3640;ACL8285RBR3040;ACL8285RBR2440;ACL8285RBM3696;ACL8285RBM3272;ACL8285RBM3096;ACL8285RBM3072;ACL8085BM2436-Product

MFR #:8385DGYR3040

EIS #:ACL8385DGY3040

MFR #:8385DGYR3040

EIS #:ACL8385DGY3040

Out of Stock

Min Qty:1

  |

Qty Increment:1

WARNING: California Proposition 65 - Cancer and Reproductive Harm - www.P65Warnings.ca.gov
more info
0
0
Dualmat is a chemically cross-linked material with different electrical resistances on each side. Because it is inherently cross-linked the material will not delaminate and is volume conductive. Unlike the competition's surface dissipative mats, the electrical properties of the Dualmat are volume dissipative. The layers are permanently dissipative with polymers that will not lose electrical properties, will not exudate and more importantly will not outgas and contaminate clean room environments. - This ESD mat is a static dissipative industrial-grade elastomer designed for use on tables and other grounded work bench surfaces. This material was developed to conform to the most stringent ESD and lead-free requirements. The material is as durable as rigid laminates, and as comfortable and appealing as softer rubber or vinyl mats. It is suitable for use with constant monitor systems.
$2,002.29 / Roll

Min Qty:1

  |

Qty Increment:1

WARNING: California Proposition 65 - Cancer and Reproductive Harm - www.P65Warnings.ca.gov
more info
0
0
Dualmat is a chemically cross-linked material with different electrical resistances on each side. Because it is inherently cross-linked the material will not delaminate and is volume conductive. Unlike the competition's surface dissipative mats, the electrical properties of the Dualmat are volume dissipative. The layers are permanently dissipative with polymers that will not lose electrical properties, will not exudate and more importantly will not outgas and contaminate clean room environments. - This ESD mat is a static dissipative industrial-grade elastomer designed for use on tables and other grounded work bench surfaces. This material was developed to conform to the most stringent ESD and lead-free requirements. The material is as durable as rigid laminates, and as comfortable and appealing as softer rubber or vinyl mats. It is suitable for use with constant monitor systems.

Attributes

General Information
Item NameTable Mat
Trade NameDualmat™
SeriesDualMat
General Features
StandardsANSI/ESD S20.20, STM 7.1, ASTM F-150, NFPA-99, UL-779, EN 100015, DIN 51953 and IEC-61340-5-1
TypeStatic Dissipative
Design & Construction
ColorDark Gray
MaterialElastomer
Technical Details
Surface Resistivity106 to 108 ohms
Electrical Properties
Resistance10^6 - 10^8 ohm
Physical Properties
Length40 ft
Surface PatternEmbossed
Thickness0.08 Inch
Width30 Inch
Dimensions30 inch x 40 ft
Environmental Condition
ResistsAbrasion
Supporting Information
For Use WithConstant Monitor Systems
