3M VTN-200 2:1 Special Purpose Heat Shrink Tubing, 3/8", 200' Per Spool, Black
MFR #:7010349778
EIS #:VTN2003/8BLK1
UPC #:00054007400721
MFR #:7010349778
EIS #:VTN2003/8BLK1
UPC #:00054007400721
In Stock
Min Qty:1
|Qty Increment:1
Pack:1 Spool/Case
3M™ Heat Shrink Tubing VTN 200 withstands various fuels, lubricants, acids and highly corrosive fluids. The tubing is easily markable using hot stamp or print wheel methods. It is perfect for use in electronic control systems, hydraulic fluid transport mechanisms and chemical plants. It withstands temperatures of 67 to 392 degrees F ( 55 to 200 degrees C). SAE AS23053/13, AMS R46846 Type 3 Class 1 Certified and RoHS 2011/65/EU Compliant.
3M™ Heat Shrink Tubing VTN-200 is a flexible tubing that provides high abrasion and cut through resistance, making it perfect for aircraft/aerospace applications. This tubing has a 2:1 shrink ratio and fluoroelastomer construction that offers superior resistance to a broad range of chemicals.
$1,609.96 / 100Foot
Pack: 1 Spool/Case
Min Qty:1
|Qty Increment:1
Pack:1 Spool/Case
3M™ Heat Shrink Tubing VTN 200 withstands various fuels, lubricants, acids and highly corrosive fluids. The tubing is easily markable using hot stamp or print wheel methods. It is perfect for use in electronic control systems, hydraulic fluid transport mechanisms and chemical plants. It withstands temperatures of 67 to 392 degrees F ( 55 to 200 degrees C). SAE AS23053/13, AMS R46846 Type 3 Class 1 Certified and RoHS 2011/65/EU Compliant.
3M™ Heat Shrink Tubing VTN-200 is a flexible tubing that provides high abrasion and cut through resistance, making it perfect for aircraft/aerospace applications. This tubing has a 2:1 shrink ratio and fluoroelastomer construction that offers superior resistance to a broad range of chemicals.
- Attributes
- Features
- Applications
Attributes
General Information
Item NameHeat Shrink Tubing
Design & Construction
ColorBlack
Insulation MaterialModified Fluoroelastomer
Minimum Shrink Temperature175 °C
Performance Details
Flame RetardantYes
Heat Aging4 hr
Low Temperature Flexibility-55 °C
Shrink Ratio2:1
Tensile Strength2400 psi
Chemical Properties
Specific Gravity1.7
Electrical Properties
Dielectric Strength500 V/Mil
Physical Properties
Elongation450%
Expandable Diameter0.375 Inch
Length200 ft
Recovered Diameter0.187 Inch
Wall Thickness0.035 Inch
Environmental Condition
Temperature Rating-55 to 200 °C
Features
- Highly resistant to cut through and abrasion
- When heated in excess of 175 °C (347 °F), VTN-200 tubing rapidly shrinks to a skintight fit
- When freely recovered, the tubing will shrink to 50% of its as-supplied internal diameter
- The recovered wall thickness is proportional to the degree of recovery
- Non-corrosive chemical effect
- Self-extinguishing
- Volume Resistivity: 10^12 Ohm-cm
- Low Temperature Flexibility: -55 °C
- Temperature rating: -55 to 200 °C
- Length: 200 ft Per Spool
- Wall Thickness: 0.035 Inch (Recovered)
Applications
- Synthetic Fuel and Hydraulic Oil Resistant Applications, Used to Protect Wiring and Component Covers in Aircraft/Aerospace Applications Including Electronic Control Systems and Hydraulic Fluid Transport Mechanisms and in Chemical Plants
