DMD-100 White Flexible Laminate Roll, 20 Mil x 36" x 36 yd
MFR #:Dacron® Mylar® Dacron®-100-FLX LAM-ROL-WHT
EIS #:DMD5105AN
Series #:Dacron® Mylar® Dacron®-100-FLX LAM-ROL-WHT
MFR #:Dacron® Mylar® Dacron®-100-FLX LAM-ROL-WHT
EIS #:DMD5105AN
Series #:Dacron® Mylar® Dacron®-100-FLX LAM-ROL-WHT
Out of Stock
Min Qty:1
|Qty Increment:1
DMD 100 Flexible Laminate, Class F Insulation. - Acuflex® DMD 100 3-ply polyester mat/polyester film laminates are constructed of high-density polyester mat and electrical grade polyester film bonded with Thermal Bond adhesive system.
$15.89 / Square YD
Min Qty:1
|Qty Increment:1
DMD 100 Flexible Laminate, Class F Insulation. - Acuflex® DMD 100 3-ply polyester mat/polyester film laminates are constructed of high-density polyester mat and electrical grade polyester film bonded with Thermal Bond adhesive system.
Product Options
Showing 1 out of 1 options
 | Length: 36 Yard | Thickness: 20 mil | Width: 36 Inch | EIS Part #: DMD5105AN | $ / Square YD |
- Attributes
- Features
- Applications
Attributes
General Information
Item NameFlexible Laminate
Trade NameDacron® Mylar® Dacron®-100
SeriesDacron® Mylar® Dacron®-100-FLX LAM-ROL-WHT
General Features
TypeTriplex
Design & Construction
ColorWhite
Insulation TypeClass F
Performance Details
Tensile Strength240 lb/Inch
Electrical Properties
Dielectric Strength21700 V
Physical Properties
Length36 Yard
Thickness20 mil
Width36 Inch
Features
- Tough, affordable laminates for a wide variety of applications
- Excellent resistance to cut-through and edge tear
- Many UL systems including Acuflex laminates are available for Class B-130 °C, Class F-155 °C, may often be used as secondary insulation through Class H-180 °C
- Wide range of constructions to optimize mechanical and electrical designs
- White version is acceptable for use in most hermetic motor applications
- Excellent moisture and chemical resistance
- 100% Resin Filled Protection
- Volume Resistivity: 10^15 Ohm-cm
- Tensile Strength: 240 lb/Inch (MD), 225 lb/Inch (CD)
Applications
- Motors
- Generators
- Transformers
- Fractional to the Largest Rotating Electrical Equipment as Slot, Phase and End-Turn Insulation
- Ground and Wrapper Insulation in Dry-type Transformers
- Well-Suited for Punched and Fabricated Parts Such as Slot Interlining Insulation and Wedges
