CHR 2355-2 Fluorinated Ethylene Propylene Tape
- MFR #2355-2
- EIS #PH22-2355-2
$46.67 - $92.77
Refine your product below or compare all choices in the
Cantidad mínima1QTY Increment1
more info
Paquete--Products You May Also Like
| Stock Status | ||||
|---|---|---|---|---|
 | 0.75 Inch | 3 Inch | $ / Roll | |
| 0.5 Inch | 3 Inch | $ / Roll more info | |
| 1 Inch | 1 Inch | $ / Roll more info |
FEP film is used for applications requiring optical clarity, quick release and abrasion resistance. The FEP backing offers excellent high temperature resistance and offers the highest electrical strength in V/Mil. FEP backing is chemically inert, thin and conformable. - The tape construction is weather resistant, stable and non-toxic. FEP film applications include high temperature coil and capacitor wrapping, composite bonding, masking and conveyor release linings.
Features
- 2355-2 tape construction is weather resistant, stable and non-toxic
- Available with or without a liner
- Chemically inert, thin and conformable
- Durable and versatile
- FEP backing offers excellent high temperature resistance
- FEP offers the highest electrical strength in V/Mil
- Temperature rating of -100 to 400 °F
Applications
- For Primary Insulation in Motor Coils, Transformers and other Electrical Components
General Information
| Item Name | Tape |
| Series | 2355-2 |
Design & Construction
| Adhesive Type | Silicone |
| Backing Material | Fluorinated Ethylene Propylene |
| Color | Clear |
Performance Details
| Adhesive Strength | 20 oz/Inch |
| Tensile Strength | 8 lb/Inch |
Electrical Properties
| Dielectric Strength | 9000 V |
Physical Properties
| Elongation | 275% |
| Length | 36 Yard |
| Thickness | 3.5 mil |
Environmental Condition
| Resists | Chemical |
| Temperature Rating | 400 °F |
