Saint-Gobain Norton® E124-5 Natural Sintered Extruded PTFE Film Roll, 5 Mil x 36 yd, MFR ID OAK124-5X1
- MFR #OAK124-5X1
- EIS #OAK124-5X1
- Series #Norton® E124-5
$66.54 / Roll
Available to Order
Refine your product below or compare all choices in the
Min QTY1QTY Increment1
more info
| Stock Status | |||
|---|---|---|---|
 | 36 Yard | $ / Roll more info |
NORTON® 124 sintered extruded PTFE film is a quality high modulus non-adhesive PTFE film manufactured by extrusion and sintering processes. The resulting film is characterized by high dielectric strength and chemical resistance, low moisture absorption and resistance to permeability. - Saint-Gobain Norton® E124-5 sintered extruded PTFE film roll. Physical properties of sintered extruded PTFE film exceed that of skived PTFE films.
Features
- NORTON® paste extruded PTFE is produced by blending fine-powder PTFE with a lubricant and pressing the film through an extrusion die
- Multiple series of calendar rollers and dry cans set the dimensions of the film and drive off the lubricant
- Paste extruded film is unsintered
- Polytetrafluoroethylene (PTFE) insulation
- Quality, high-temperature insulation
- Excellent service and availability
- Customized products
- Tensile Strength: 6000 psi
- Temperature Rating: -100 to 500 °F
Applications
- Primary Wire and Cable Insulation, Coil Winding, Premium Gasketing and Diaphragm Applications Where a High Modulus PTFE Film Is Required
General Information
| Item Name | Sintered Extruded PTFE Film |
| Trade Name | Norton® E124 |
| Series | Norton® E124-5 |
Design & Construction
| Adhesive | No |
| Color | Natural |
Performance Details
| Tensile Strength | 6000 psi |
Electrical Properties
| Dielectric Strength | 1100 V |
Physical Properties
| Length | 36 Yard |
| Elongation | 300% |
| Thickness | 5 Mil |
