SCS 8901 Mat Kit, 2-Layer Rubber, Gray

• Dissipative Dual Layer Rubber Material
  Provides a worksurface that does not generate a static charge and will control the discharge rate from all conductors (including ESD susceptible items) that are placed on the surface
• 2-Layer Neoprene Rubber Material
  Constructed using a top color layer of static dissipative neoprene rubber laminated to a bottom black layer of conductive neoprene rubber
• High Strength Vulcanized Synthetic Neoprene Rubber Heat and Chemical Resistant
  Designed to withstand abrasion, stretching, and tearing and may be used in soldering applications with flux and other chemicals
• Ultraviolet (UV) Stabilizer Additives
  Stabilizes color retention, ensures ESD performance over time and eliminates surface layer deterioration resulting in cracking when the product is flexed
• Compatible with Continuous or Constant Monitors
• Free of chlorine
  No danger of toxic outgassing
• Lead-free ROHS Compliant
• Made in the United States of America with Globally Sourced Material

Table Mat Kit Includes:

• (1) Table Roll, size as specified
• (1) 3048 15 foot (4.6 m) Ground Cord
• (2) 3034 Snap Fasteners (installed)

8900 Series Dissipative Rubber Mats and Rolls

• Color: Blue
• Type: Table Mat
• Application: ESD safe rubber matting provides protection against static discharge and resistant against solder, heat, and most common solvents
• Construction: 2-Layer Synthetic Neoprene Rubber
• Dimensions: 0.065 inch x 24 inch x 48 inch
• Gauge/Thickness: 0.065 in (1.7mm)
• Performance: Meets ANSI/ESD S20.20 and ANSI/ESD S4.1
• Resistance To Ground (Rtg): 1 x 10⁶ less than 1 x 10⁹ (Top Layer)
• Surface Resistance (Rtt): 1 x 10⁶ less than 1 x 10⁹ (Top Layer) less than 1 x 10⁵ (Bottom Layer)
• RoHS Compliant: Yes
• Tolerance: Width +/- 0.250 inch Length +/- 0.250 inch Thickness +/- 10%
