CHR N203 Nomex Aramid Paper Tape, 1-1/4" x 60 yd x 3.6 Mil, White
- MFR #N203
- EIS #CHRN203X1.25
Requires Quote / Roll
Available to Order
Min QTY1QTY Increment1
more info
Why Buy From EIS?
- Authorized Distributor
- Fast Shipping
- Technical Support Available
Products You May Also Like
Products You May Also Like
CHR N203 is manufactured from a 2 Mil thick Nomex aramid paper backing material with 1.6 Mil of flame retardant acrylic pressure sensitive adhesive. It was developed in response to Permacel discontinuing P262. - Offers excellent heat and flame resistance, as well as excellent mechanical strength. It is resistant to acids, alkalis, refrigerants and various wire enamels and varnishes. N203 has a silicone adhesive and is capable of meeting UL Guide OANZ2, File E51201.
Features
- Temperature rating of -20 to 350 °F
Applications
- For Coil Wrapping, Capacitor, Transformer and Electric Motor Insulation and Attachment
General Information
| Item Name | Electrical Tape |
| Series | N203 |
Design & Construction
| Adhesive Type | Acrylic |
| Backing Material | Nomex Aramid Paper |
| Color | White |
Performance Details
| Adhesive Strength | 42 oz/Inch |
| Breaking Strength | 27 lb/Inch |
| Flame Retardant | Yes |
| Tensile Strength | 27 lb/Inch |
Electrical Properties
| Dielectric Strength | 2800 V |
Physical Properties
| Elongation | 8% |
| Width | 1.25 Inch |
| Length | 60 Yard |
| Thickness | 3.6 mil |
Environmental Condition
| Resists | Acid, Alkalis, Refrigerant, Various Wire Enamel and Varnish |
| Temperature Rating | 350 °F |
