Leeson M1130118.00 DC Subfractional Motor, 1/8 HP, 1750 rpm, 230VAC, 34D42CZ Frame, TENV, 42 C-Face Mount
EIS #:MOTM1130118
UPC #:00069172009137
EIS #:MOTM1130118
UPC #:00069172009137
In Stock
Min Qty:1
|Qty Increment:1
Precision sub fractional horsepower DC permanent magnet motors designed for use with full wave non-filtered SCR controls for adjustable speed applications requiring dynamic braking and constant torque throughout the speed range - Leeson M1130118.00 DC Subfractional Motor, 1/8 HP, 1750 rpm, 230VAC, 34D42CZ Frame, TENV, 42 C-Face Mount
$679.90 / each
Min Qty:1
|Qty Increment:1
Precision sub fractional horsepower DC permanent magnet motors designed for use with full wave non-filtered SCR controls for adjustable speed applications requiring dynamic braking and constant torque throughout the speed range - Leeson M1130118.00 DC Subfractional Motor, 1/8 HP, 1750 rpm, 230VAC, 34D42CZ Frame, TENV, 42 C-Face Mount
- Attributes
- Features
- Applications
Attributes
General Information
Item NameDC Subfractional Motor
Trade NameLeeson
General Features
TypeDN, Sub-FHP, SCR Rated
StandardsUL Listed, CSA Certified, CE Certified
Design & Construction
Bearing TypeBall
Enclosure TypeTotally Enclosed Non-Ventilated
DutyContinous
Insulation TypeClass F
MaterialRolled Steel
Mounting Type42 C-Face
RotationReversible
Shaft PositionHorizontal
Performance Details
Speed Rating1750 rpm
Full Load Efficiency75.7%
Torque Rating72 lb-ft
Electrical Properties
Amperage Rating0.7 A
Armature Voltage180 VDC
Form Factor1.38
HP Rating0.125 HP
Service Factor1
Voltage Rating230 VAC
Physical Properties
Frame Size34
Dimensions7.81 Inch L x 4.25 Inch W
Shaft Diameter0.5 Inch
Environmental Condition
Temperature Rating40 °C
Features
- NEMA DC, explosion proof, SUB-FHP, wash-down, IEC and low voltage motors available
- Dynamically balanced armatures
- 30:1 constant torque operation
- Compact, space saving design
- Reversible rotation
- Permanent magnet designs
- PWM or SCR rated and low voltage input voltage designs
- Removable bolt-on base
- Oversized brushes for long brush life
- Easy access to brushes
- Constant torque throughout speed range
- DC Controls available to change the speed of the motors
- High starting torque
- Amperage Rating: 0.7A DC (Full Load)
Applications
- DC Motors Are Typically Used In Applications Requiring Motor Speed Adjustment, Constant Torque Through The Speed Range And Reversing Capabilities. Applications Would Include: Pumps, Conveyors, Turntables, Textile Machinery, Treadmills, Reeling Equipment, Sports Equipment And Medical Equipment
