Von Roll/John C Dolph Dolphon® CC-1120 Two Part Elastomeric Potting Compound Resin
- MFR #Dolphon® CC-1120
- EIS #PH21-Dolphon CC-1120
$379.85
Refine your product below or compare all choices in the
Cantidad mínima1QTY Increment1
more info
Paquete--| Stock Status | |||
|---|---|---|---|
 | 1 gal | $ / Kit |
Von Roll Dolphon® CC-1120 Two Part Elastomeric Potting Compound Resin, Amber. - DOLPHON CC-1120 is a unique two-part, room temperature curing, potting compound with low viscosity and easy pourability.
Features
- Convenient mix ratio
- Easy mixing
- Low viscosity for easy pouring over sand or fillers
- Long pot life
- Room temperature cure with low exotherm
- Very low shrinkage
- Easy removal and repair
- Excellent electrical properties
- High resistance to degradation by heat or pressure
- Finished product can be used continuously at 150 °C and intermittently at temperatures up to 180 °C
- No embedment stress
- Flexible at temperatures as low as -65 °C
- Removable
- Repairable
- Viscosity: 1400 to 1600 cps at 25 °C
- Thermal Conductivity: 2.2 BTU-Inch/hr-ft^2- °F
- Density: 7.5 - 8.0 lb/gal
- Gel Time: 8 - 12 min
- Viscosity: 1400 - 1600 cP
Applications
- Filling Electromagnets, Potting Transformers
- Potting Electronic Modules, Encapsulating Thick Film Circuits
- Circuit Boards, Magnetic Chucks, Conformal Coating
General Information
| Item Name | Compound Resin |
| Trade Name | Dolphon® |
| Series | Dolphon® CC-1120 |
General Features
| Type | Two Part Elastomeric Potting |
Design & Construction
| Color | Amber |
| Cure Type | Room Temperature |
| Insulation Type | Class B |
Performance Details
| Full Cure Time | 3 - 5 hr |
| Gel Time | 8 min |
Chemical Properties
| Viscosity | 1400 cP |
Electrical Properties
| Dielectric Strength | 620 V/mil |
Physical Properties
| Container Type | Kit |
| Density | 7.5 lb/gal |
| Hardness | 30 - 40 Shore D |
Environmental Condition
| Temperature Rating | 130 °C |
