$33.29
Refine your product below or compare all choices in the
Cantidad mínima1QTY Increment1
more info
Paquete--Why Buy From EIS?
- Authorized Distributor
- Fast Shipping
- Technical Support Available
Products You May Also Like
| Stock Status | |||
|---|---|---|---|
| 1 Inch | $ / Roll Paquete: 9/Case more info | ||
| 3 Inch | $ / Roll Paquete: 8/Case more info |
3M 9471LE clear transfer tape comes in acrylic adhesive. The variances in thickness often make an important difference in proper performance. This transfer tape has a 2.3 Mil thick. Products in this category feature a liner on the back which you peel away from to expose the adhesive material before applying to the substrate. The liner material for this product is composed of polycoated kraft paper. - High strength acrylic adhesive that provides a very high bond strength to most surfaces. Excellent bond to low surface energy plastics such as polypropylene. Extremely smooth adhesive for excellent graphics appearance. Polycoated kraft liner enables easy die-cutting. Double linered for selective die-cutting, Excellent adhesion to lightly oiled surfaces typical of machine parts.
Features
- For adhesive strength see TDS
- Temperature rating of -40 to 300 °F
Applications
- For Logo Bonding, Touchpad Bracket Assembly, Battery Bonding, Low Surface Energy Bonding, Memory Card Bonding, Case Assembly, Camera Module Assembly
General Information
| Item Name | Adhesive Transfer Tape |
| Series | 9471LE |
General Features
| Shelf Life | 18 Months |
| Storage Temperature | 21 °C |
Design & Construction
| Adhesive Type | Acrylic |
| Color | Clear/Tan Liner |
| Liner Material | Polycoated Kraft Paper |
Performance Details
| Shear Strength | 8 psi |
Physical Properties
| Adhesive Thickness | 2 mil |
| Core Size | 3 Inch |
| Length | 60 Yard |
| Liner Thickness | 4.2 mil |
| Width | 1 Inch |
| Thickness | 2.3 mil |
Environmental Condition
| Resists | Humidity, UV, Water, Temperature, Chemical |
| Temperature Rating | 300 °F |
Documentos
No Documents Found
