DuPont NKN White Triplex Polyimide Film Laminate Roll, MFR ID Nomex® Kapton® Nomex®-ROL-WHT
- MFR #:Nomex® Kapton® Nomex®-ROL-WHT
- EIS #:PH21-Nomex Kapton Nomex-ROL-WHT
- Series #:Nomex® Kapton® Nomex®-ROL-WHT
- MFR #:Nomex® Kapton® Nomex®-ROL-WHT
- EIS #:PH21-Nomex Kapton Nomex-ROL-WHT
- Series #:Nomex® Kapton® Nomex®-ROL-WHT
Nomex® Laminates type NKN is triplex laminates constructed of calendered Nomex® paper bonded to Kapton® polyimide film with a proprietary high temperature adhesive system. These laminates are designed not to delaminate or blister at high temperatures. The calendered Nomex® paper provides long-term thermal stability, as well as improved propagation tear strengths. - Nomex® laminates type NKN is triplex laminates constructed of calendered Nomex® paper bonded to Kapton® polyimide film with a proprietary high temperature adhesive system.
$136.58
- $166.52
Select from the options below
Nomex® Laminates type NKN is triplex laminates constructed of calendered Nomex® paper bonded to Kapton® polyimide film with a proprietary high temperature adhesive system. These laminates are designed not to delaminate or blister at high temperatures. The calendered Nomex® paper provides long-term thermal stability, as well as improved propagation tear strengths. - Nomex® laminates type NKN is triplex laminates constructed of calendered Nomex® paper bonded to Kapton® polyimide film with a proprietary high temperature adhesive system.
Product Options
Showing 2 out of 2 options
 | Length: 36 Yard | Thickness: 13 mil | EIS Part #: NKN535A | $ / Square YD | |
| Length: 100 Yard | Thickness: 7 mil | EIS Part #: NKN2221M | $ / Square YD |
- Attributes
- Features
- Applications
Attributes
General Information
Item NamePolyimide Film Laminate
Trade NameNomex® Kapton® Nomex®
SeriesNomex® Kapton® Nomex®-ROL-WHT
General Features
TypeTriplex
Design & Construction
ColorWhite
Insulation TypeClass H
Physical Properties
Width36 Inch
Features
- The KAPTON® polyimide film in these 2- and 3-ply laminates contributes high dielectric strength, as well as good initial tear strength and tensile properties
- High heat resistance
- Thermal endurance and Class H categorization
- Availability in narrow widths
- These laminates are designed not to delaminate or blister at high temperatures
- Good initial tear strength and tensile properties
- Nomex-Kapton laminates in two-ply or three-ply consist of Nomex aramid paper laminated to Kapton polyimide film
- These laminates have exceptional mechanical strength and flexibility
- Volume Resistivity: 10^15 Ohm-cm
Applications
- Ideal for Use as Slot, Phase, Turn-To-Turn, Liner, and Barrier Insulation in Rotating Motors and Other Machines
- Transformer and Inductor Windings
- Very Popular in Motor and Other Electrical Applications
