Parker 62-15-0808-1671 Cho-Therm® High Power Thermal Insulator Pad, 8" L x 8" W x 0.38 mm T, White
- MFR #62-15-0808-1671
- EIS #CHOTHERM167102
$199.64 / Sheet
Available to Order
Min QTY1QTY Increment1
more info
Why Buy From EIS?
- Authorized Distributor
- Fast Shipping
- Technical Support Available
Products You May Also Like
Cho-Therm 62-15-0808-1671 high-power thermal insulator pads are thermally conductive materials designed for use where the highest possible thermal, dielectric and mechanical properties are required. Fiberglass cloth reinforcement strengthens Cho-Therm pads against tear, cut-through and punctures. These materials are available in sheet form and die-cut configurations. - An 62-15-0808-1671 optional acrylic adhesive layer (with PSA) is available on one or two sides. With a proven track record spanning several decades in multiple applications, these products are the first choice for high-end power supplies, industrial, aerospace and military/avionics applications.
Features
- Excellent thermal properties
- High dielectric strength
- Excellent mechanical strength and puncture resistance
- 100% inspected for dielectric properties on every sheet
- Acrylic PSA attachment option available
- Extremely low NASA outgassing
- Proven through decades of use in demanding military and aerospace applications
- Highest reliability in rigorous applications
Applications
- For High-End Power Supplies, Industrial, Aerospace, and Military/Avionics Applications
General Information
| Item Name | Thermal Insulator Pad |
| Trade Name | Cho-Therm® |
General Features
| Type | High Power |
| Standards | UL Listed, RoHS Compliant |
| Shelf Life | Indefinite |
Design & Construction
| Color | White |
| Form | Solid |
Performance Details
| Tensile Strength | 3000 psi |
Chemical Properties
| Specific Gravity | 1.55 |
Physical Properties
| Elongation | 15% |
| Hardness | 80 Shore A |
| Odor/Scent | Odorless |
Environmental Condition
| Temperature Rating | -40 to 200 °C |
