The image shown is representative of the product family and may not specifically be the individual item.
0

Leeson LM29666 Hydraulic Submersible Elevator Pump Motor, 30 HP, 3600 rpm, 160Z Frame

  • MFR #LE-230-RGBF1-ODP-SEPM
  • EIS #MOTLM29666
  • UPC #00069172040000
$2,683.76 / Piece
Available to Order
Refine your product below or compare all choices in the
Min QTY1QTY Increment1
more info
PROP_65_CANCER
WARNING: California Proposition 65 - Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Constructed for low noise and low vibration. Wye start/delta run. Thermostat protected windings. Two stainless steel nameplates furnished. 80 starts per hour. Dual rated nameplates for 80 & 120 starts/hour. Designed for belt driven pumps. Intermittent duty. Class F Insulated. F1 mounting. Ball bearings with grease fittings and automatic relief. NEMA dimensions.

General Information

Item NameSubmersible Elevator Pump Motor
Trade NameLeeson

SeriesLE-230-RGBF1-ODP-SEPM

General Features

StandardsUL Listed, CSA Approved
TypeDefinite Purpose, Hydraulic

Design & Construction

Bearing TypeBall
ConstructionSteel Frame
DutyIntermittent
Enclosure TypeOpen Dripproof
Insulation TypeClass F
KVA CodeG
Mounting TypeRigid Base, F1
RotationReversible

Performance Details

Full Load Efficiency79.9%
1/2 Load Efficiency87.5%
3/4 Load Efficiency88.5%
Speed Rating3600 rpm

Electrical Properties

Frequency Rating60
Full Load Ampere80 A
Full Load Power Factor88%
1/2 Load Power Factor61%
HP Rating30 HP
Locked Rotor Ampere250 A
Phase3-Phase
Service Factor1
3/4 Load Power Factor74.5%
Voltage Rating230 V

Physical Properties

Weight129 lb
Dimensions9.53 Inch W x 13.35 Inch H
Frame Size160

Environmental Condition

Temperature Rating70 °C
