MFR #:2220-VF
EIS #:PH19-2220-VF
Series #:2220-VF
MFR #:2220-VF
EIS #:PH19-2220-VF
Series #:2220-VF
The Kester 2220-VF is a high activity, organic flux designed for lead-free automated wave solder applications. The flux will provide maximum capillary wetting action up plated through holes, making it ideal for use on multilayer boards. Along with this enhanced activity, 2220-VF flux produces bright, shiny solder joints and the residue after soldering is effectively removed in standard water cleaning systems. - 2220-VF is free of volatile organic compounds (VOC), which provides optimal heat stability for the lead-free wave soldering process. The use of VOC-free solvents eliminates the use of ozone depleting chemicals which results in an environmentally friendly process.
$141.43
Select from the options below
The Kester 2220-VF is a high activity, organic flux designed for lead-free automated wave solder applications. The flux will provide maximum capillary wetting action up plated through holes, making it ideal for use on multilayer boards. Along with this enhanced activity, 2220-VF flux produces bright, shiny solder joints and the residue after soldering is effectively removed in standard water cleaning systems. - 2220-VF is free of volatile organic compounds (VOC), which provides optimal heat stability for the lead-free wave soldering process. The use of VOC-free solvents eliminates the use of ozone depleting chemicals which results in an environmentally friendly process.
Product Options
Showing 2 out of 2 options
Container Size: 1 gal | EIS Part #: KES2220VFG | $ / US gallon | ||
Container Size: 5 gal | EIS Part #: KES2220VF5G | $ / US gallon |
- Attributes
- Features
Attributes
General Information
Item NameSoldering Flux
Series2220-VF
General Features
Shelf Life12 Months
Storage Temperature4 to 25 °C
Design & Construction
ColorAmber
FormLiquid
Flux TypeOrganic Activated or Water Soluble
Performance Details
Vapor Pressure23 hPa
Chemical Properties
Chemical CompositionGlycolic Acid, Guanidinium Chloride, Cyclohexylammonium Chloride, Water
Flux Formula2220-VF
Specific Gravity1.06
Physical Properties
Odor/ScentMild
Supporting Information
Flux DesignatorORH0
RoHS Info2002/95/EC Directive
Features
- Thermally stable and VOC-free to allow for effective high temperature soldering
- High activity
- Minimizes icicling and bridging
- Chemically compatible with most solder masks and board laminates
- High ionic cleanliness and no surface insulation resistance degradation
- Compatible with leaded and lead-free wave soldering applications
- Temperature rating of 49 to 60 °C
- Vapor pressure of 23 hPa at 20 °C
