Atkins and Pearce Suflex® HD Class H Grade A Silicone Rubber Coated Sleeving, 9 AWG, 250' Per Spool, Natural, MFR ID SRA09NFE
- MFR #:2810009111
- EIS #:SRA09NFE
- Series #:Suflex® HD-A
- MFR #:2810009111
- EIS #:SRA09NFE
- Series #:Suflex® HD-A
Available to Order
Min Qty:1
|Qty Increment:1
Suflex silicone rubber-HD fiberglass sleeving consists of a silicone elastomer securely bonded to its supporting fiberglass braid. It is designed to remain flexible over operating temperature extremes of -75 °C to 220 °C. - Suflex silicone rubber-HD provides top performance in high-temperature applications where no other sleeving can be used.
$49.04 / 100Foot
Min Qty:1
|Qty Increment:1
Suflex silicone rubber-HD fiberglass sleeving consists of a silicone elastomer securely bonded to its supporting fiberglass braid. It is designed to remain flexible over operating temperature extremes of -75 °C to 220 °C. - Suflex silicone rubber-HD provides top performance in high-temperature applications where no other sleeving can be used.
- Attributes
- Features
- Applications
Attributes
General Information
Item NameSilicone Rubber Coated Sleeving
Trade NameSuflex®
SeriesSuflex® HD-A
Design & Construction
Braid TypeFiberglass
ColorNatural
GradeA
Insulation MaterialSilicone Rubber
Insulation TypeClass H
Insulation Coating TypeSilicone
NEMA SpecificationNEMA TF-1 Type 5
Performance Details
Flame RetardantYes
Electrical Properties
Breakdown Voltage6000 V
Dielectric Strength15 kV
Voltage Rating600 V
Physical Properties
Gauge9 AWG
Inside Diameter0.118 Inch
Length250 ft
Features
- High durometer rating, providing excellent abrasion resistance and rigidity
- Designed to maintain flexibility over wide operating temperature extremes, -75 °C to 220 °C
- Resistant to ozone, corona, radiation, moisture, compression set, weathering, fungus and chemical attack
- Specialty colors available by request
- 15 kV grade available by request
- It is particularly well suited as heavy duty insulation where subjected to high heat such as in die-casting and plastic molding and in numerous military electronic application
- Dielectric Grade: A
- Length: 250 ft Per Spool
- Breakdown Voltage: 6000 - 8000V
- Temperature Rating: -75 to 200 °C
Applications
- High Altitude and Aerospace Applications
- Apparatus Leads, Appliance and Fixture Wire Insulation, Heating Cable, Ignition Systems, Relay Leads and Aircraft Wire Where a 200 °C Thermal Rating Is Required
