Dow Corning silicone encapsulants are supplied as two-part liquid component kits. When liquid components are thoroughly mixed, the mixture cures to a flexible elastomer, which is suited for the protection of electrical/electronic applications. For most uses, silicone elastomers should be operational over a temperature range of -45 to 200 °C for long periods of time. - 2-part, clear, 10:1, heat cure, good strength, UL and Mil Spec, same as Sylgard 184 but with longer working time. In applications requiring adhesion, priming will be required for the silicone encapsulants.
$326.12
- $1,263.46
Select from the options below
Dow Corning silicone encapsulants are supplied as two-part liquid component kits. When liquid components are thoroughly mixed, the mixture cures to a flexible elastomer, which is suited for the protection of electrical/electronic applications. For most uses, silicone elastomers should be operational over a temperature range of -45 to 200 °C for long periods of time. - 2-part, clear, 10:1, heat cure, good strength, UL and Mil Spec, same as Sylgard 184 but with longer working time. In applications requiring adhesion, priming will be required for the silicone encapsulants.
Product Options
Showing 2 out of 2 options
Page 1 of 1
more info
Container Size:
3.9kg
EIS Part #:
DC182X3.9KG
$ / Kit
Pack: 4/Carton
Container Size:
0.5kg
EIS Part #:
DC182X0.5KG
$ / Kit
Page 1 of 1
more info
Attributes
Features
Applications
Attributes
General Information
Item NameSilicone Elastomer
Trade NameSylgard®
Series182
General Features
Shelf Life24 Months
StandardsWEEE/RoHS Compliant
Storage TemperatureBelow 25 °C
Design & Construction
Color - Part-AColorless
Color - Part-BColorless
Cure TypeHeat Cure
Form - Part-ALiquid
Form - Part-BLiquid
Chemical Properties
Composition - Part-ASilicone
Composition - Part-BSilicone Resin
Specific Gravity - Part-A1.03
Viscosity - Part-A110 cSt
Viscosity - Part-B110 cSt
Physical Properties
Container TypeKit
Hardness51 Shore A
Odor/Scent - Part-ASlight
Features
No exotherm during cure
No solvents or cure by products
Deep section cure
Repairable
Good dielectric properties
Flexible elastomer
Easy-to-use and repair
Transparent for easy board and part inspection
Flexible
Low stress
Applications
For General Potting Applications, Power Supplies, Connectors, Sensors, Industrial Controls, Transformers, Amplifiers, High Voltage Resistor Packs, Relays, Adhesive/encapsulant for Solar Cells, Adhesive Handling Beam Lead Integrated Circuits During Processing
