Requires Quote / Pail
Available to Order
Min QTY1QTY Increment1
more info
Products You May Also Like
Dow Corning brand silicone 10 to 1 encapsulants are supplied as two-part liquid component kits. When liquid components are thoroughly mixed, the mixture cures to a flexible elastomer, which is well suited for the protection of electrical/electronic applications. Dow Corning silicone encapsulants cure without exotherm at a constant rate regardless of sectional thickness or degree of confinement. - Standard silicone encapsulants require a surface treatment with a primer in addition to good cleaning for adhesion while primerless silicone encapsulants require only good cleaning. Sylgard 184 silicone elastomer is suitable for LED lighting encapsulation, industrial controls, high voltage resistor packs.
Features
- Flowable
- Room temperature and heat cure
- Good dielectric properties
- Rapid, versatile cure processing controlled by temperature
- High transparency allows easy inspection of components
Applications
- For Power Supplies, Connectors, Sensors, Industrial Controls, Transformers, Amplifiers, High Voltage Resistor Packs, Relays, Adhesive/Encapsulant for Solar Cells, Adhesive Handling Beam Lead Integrated Circuits During Processing
General Information
| Item Name | Silicone Elastomer |
| Trade Name | Sylgard® |
| Series | 184P |
General Features
| Shelf Life | 720 Days |
| Standards | WEEE/RoHS Compliant |
Design & Construction
| Color | Colorless |
| Cure Type | Room Temperature/Heat Cure |
| Form | Liquid |
Chemical Properties
| Composition | Silicone Resin |
| Specific Gravity | 1.03 |
| Viscosity | 110 cSt |
Physical Properties
| Container Size | 45 lb |
| Container Type | Pail |
| Hardness | 43 Shore A |
| Odor/Scent | Slight |
