3M 1345 EMI Embossed Tin-Plated Copper Foil Shielding Tape
- MFR #1345
- EIS #PH22-1345
$37.21 - $304.11
Refine your product below or compare all choices in the
Min QTY1QTY Increment1more infoPack--
| Stock Status | |||
|---|---|---|---|
 | 2.25 Inch | $ / Roll | |
 | 1.75 Inch | $ / Roll | |
 | 2 Inch | $ / Roll | |
 | 2.5 Inch | $ / Roll |
3M embossed tin-plated copper foil tape 1345 shall be coated on one side with pressure sensitive adhesive, which shall not require heat, moisture or other preparation prior to or subsequent to application. The adhesive coating shall be smooth and uniform and be free of lumps and bare spots. There shall be no separator between adjacent layers of the roll. The tape shall perform at a temperature of -40 °F (-40 °C) to 266 °F (130 °C) without substantial loss of tensile or electrical properties. - 3M embossed tin-plated copper foil tape 1345 consists of an embossed 1 oz dead soft tin-plated copper foil backing and an aggressive pressure sensitive acrylic adhesive. The edges of the embossed pattern pressed into the foil cut through the adhesive layer to establish reliable metal-to-metal contact between the backing and the application substrate.
Features
- Embossed deadsoft 1 oz tin plated copper foil backing
- Offers stable contact resistance and superior shielding effectiveness
- Embossed backing cuts through the layer of adhesive for establishing contact between the backing and the application substrate
- Flame retardant
- Conductivity through the adhesive
- Supplied on a removable liner for easy handling and die-cutting
- Electrical resistance of 0.001 ohm
- Backing thickness of 1.4 Mil
- Temperature rating of -40 to 130 °C
Applications
- For Grounding and EMI Shielding in Equipment, Components, Shielded Rooms
General Information
| Item Name | Shielding Tape |
| Trade Name | 3M |
| Series | 1345 |
General Features
| Type | EMI, Embossed |
| Shelf Life | 60 Months |
Design & Construction
| Adhesive Type | Acrylic |
| Backing Material | Tin-Plated Copper Foil |
| Color | Natural |
Performance Details
| Adhesive Strength | 45 oz/Inch |
| Breaking Strength | 25 lb/Inch |
| Flame Retardant | Yes |
Physical Properties
| Core Size | 3 Inch |
| Width | - |
| Length | 18 Yard |
| Thickness | 4 mil |
Environmental Condition
| Temperature Rating | 130 °C |
