Rea Magnet Wire SDG Single Build Round Magnet Wire

The image shown is representative of the product family and may not specifically be the individual item.
The image shown is representative of the product family and may not specifically be the individual item.
The image shown is representative of the product family and may not specifically be the individual item.
The image shown is representative of the product family and may not specifically be the individual item.
The image shown is representative of the product family and may not specifically be the individual item.

MFR #:TTAI SDGPC121

EIS #:PH15-TTAI SDGPC121

Series #:TTAI SDGPC121

MFR #:TTAI SDGPC121

EIS #:PH15-TTAI SDGPC121

Series #:TTAI SDGPC121

0
0
Round single build Dacron glass is a served filament that is applied over the magnet wire conductor. Dacron glass is a combination of glass and polyester fibers. The fibers may be served over bare conductor or Therm-Aimid insulated conductors. Daglas-film constructions provide improved electrical properties. Polyester fiber/glass fiber combination provides freedom from fraying and superior adhesion. - Round single build Therm-Aimid is a dual film insulation system composed of THEIC modified polyester with a polyamideimide (AI) overcoat. Therm-Aimid, designed for continuous operation at 200 °C, provides superior abrasion resistance, solvent resistance and overload protection.
$1,019.00
 - $1,614.00
Select from the options below
0
0
Round single build Dacron glass is a served filament that is applied over the magnet wire conductor. Dacron glass is a combination of glass and polyester fibers. The fibers may be served over bare conductor or Therm-Aimid insulated conductors. Daglas-film constructions provide improved electrical properties. Polyester fiber/glass fiber combination provides freedom from fraying and superior adhesion. - Round single build Therm-Aimid is a dual film insulation system composed of THEIC modified polyester with a polyamideimide (AI) overcoat. Therm-Aimid, designed for continuous operation at 200 °C, provides superior abrasion resistance, solvent resistance and overload protection.

Product Options

Showing 4 out of 4 options
Wire Size
17 AWG
EIS Part #
RW17TTAISDEPER
$ / US pound
Wire Size
16 AWG
EIS Part #
RW16TTAISDEPER
$ / US pound
Wire Size
15 AWG
EIS Part #
RW15TTAISDEPER
$ / US pound
Wire Size
14 AWG
EIS Part #
RW14TTAISDEPER
$ / US pound

Attributes

General Information
Item NameMagnet Wire
SeriesTTAI SDGPC121
General Features
TypeSingle Build
Design & Construction
ColorNatural
Insulation MaterialSingle Daglas/Theic Modified Polyester Overcoated with Polyamide-imide
MaterialCopper
NEMA RatingMW 45-C
ShapeRound
Physical Properties
Reel Diameter6.53 Inch
Reel Hub Diameter1.536 Inch
Reel Weight79 lb
Reel Width7 Inch
