Belden SIL0830808BDB Tinned Copper Hookup Wire, 8 AWG, 54/25 Strand, 500 ft Spool, Black
- MFR #30808 010500
- EIS #SIL0830808BDB
$6,298.25 / 1000Foot
Available to Order
Min QTY1QTY Increment1
more info
UL3125 wire has excellent physical and mechanical strength properties. Some rigid varnishes may cause cracking when the wire is severely bent.
The glass braid UL3125 offers abrasion resistance, is treated to prevent fraying. The silicone insulation strips easy and clean. Silicone rubber (braidless silicone) lead wire features easy and clean stripping without the problems associated with glass braid lead wire.
Applications
- For High-Temperature Applications in Motors, Lighting Fixtures, Clothes Dryers, Stoves, Therapeutic and Electronic Devices
General Information
| Item Name | Hookup Wire |
General Features
| Standards | UL 3125 Listed, CSA SEW-2 Certified |
Design & Construction
| Color | Black |
| Conductor Stranding | 54/25 |
| Insulation Material | Silicone with Lacquered Glass Braid Covering |
| Material | Tinned Copper |
| Wire Type | AWM |
Electrical Properties
| Voltage Rating | 600V |
Physical Properties
| Length | 500 ft Spool |
| Thickness | 0.060 Inch |
| Number of Conductors | 1 |
| Outside Diameter | 0.313 Inch |
