3M DMD-180 Triplex High Performance Flexible Laminate Sheet, 15 Mil x 24" x 36", MFR ID 7010399972

EIS-3M Electrical OEM Materials-Insulation Paper and Film-DMDH33301-Images
  • MFR #:7010399972
  • EIS #:DMDH55501
  • Series #:Dacron® Mylar® Dacron®-180-SHT
  • UPC #:00080611460488
  • MFR #:7010399972
  • EIS #:DMDH55501
  • Series #:Dacron® Mylar® Dacron®-180-SHT
  • UPC #:00080611460488
In Stock | Ready to Ship

Min Qty:1

  |

Qty Increment:1

WARNING: California Proposition 65 - Cancer and Reproductive Harm - www.P65Warnings.ca.gov
more info
0
0
It can be used in electrical insulation systems up to Class 220(R) per UL 1446 and IEC Std. 60085. 3M Innovative Paper Technologies UL Recognized Insulation Systems may be found on UL’s Electrical Insulation Systems database at http.//database.ul.com/systems/. 3M DMD 180 Triplex High Performance Flexible Laminate.
$11.39 / Sheet

Min Qty:1

  |

Qty Increment:1

WARNING: California Proposition 65 - Cancer and Reproductive Harm - www.P65Warnings.ca.gov
more info
0
0
It can be used in electrical insulation systems up to Class 220(R) per UL 1446 and IEC Std. 60085. 3M Innovative Paper Technologies UL Recognized Insulation Systems may be found on UL’s Electrical Insulation Systems database at http.//database.ul.com/systems/. 3M DMD 180 Triplex High Performance Flexible Laminate.

Product Options

Showing 1 out of 1 options
EIS-3M Electrical OEM Materials-Insulation Paper and Film-PH21-Dacron Mylar Dacron-180-ROL-Images
Thickness:
15 mil
EIS Part #:
DMDH55501
$ / Sheet

Attributes

General Information

Item NameHigh Performance Flexible Laminate
Trade Name3M

SeriesDacron® Mylar® Dacron®-180-SHT

General Features

TypeTriplex

Design & Construction

Insulation TypeClass H

Performance Details

Moisture Absorption<1%
Tensile Strength127 lb/Inch

Electrical Properties

Dielectric Strength11000 V

Physical Properties

Elongation17% (MD), 92% (CD)
Length36 Inch
Thickness15 mil
Width24 Inch

Environmental Condition

Temperature Rating180 °C
