Leeson 131561 General Purpose Motor, 3 HP, 1800 rpm, 230V, 184T Frame, ODP, Rigid Base Mount
- MFR #131561.00
- EIS #MOT131561
- UPC #00069172001804
$1,618.82 / each
Available to Order
Min QTY1QTY Increment1
more info
Products You May Also Like
General Purpose Motor, Bearing Type: Ball, Enclosure Type: Open Dripproof, Construction: Steel Frame, Frequency Rating: 60 Hz, Mounting Type: Rigid Base, Frequency Rating: 60 Hz, Temperature Rating: 40 deg C, Voltage Rating: 230V.
Shielded ball bearings for direct coupled applications. Continuous duty. Open Dripproof and Steel Frame
Features
- Dimensions: 14.19 Inch L
- Full load ampere: 33.8A at 115V, 16.9A at 230V
- Service factor ampere: 37.8A at 115V, 18.9A at 230V
- Voltage rating: 115/230V
- Shaft diameter: 1.1245 - 1.1250 Inch
- Torque rating: 9 lb-ft (Full Load), 18.4 lb-ft (Break Down), 17.5 lb-ft (Pull Up), 24.6 lb-ft (Locked Rotor)
- HP rating: 3 HP at 60 Hz
- Speed rating: 1800 rpm at 60 Hz
- Power rating: 2.24kW at 60 Hz
- Service factor: 1.15 at 60 Hz
- Full load efficiency: 75.5% at 60 Hz
- Full load power factor: 76% at 60 Hz
Applications
- For use where Water and Dust Exposure is Minimal. Ideally Suited for use on Pumps, Compressors, Blowers, Fans and other Standard Industrial Applications
General Information
| Item Name | General Purpose Motor |
| Trade Name | Leeson |
General Features
| Standards | UL Listed, CSA Approved, CE Approved |
Design & Construction
| Bearing Type | Ball |
| Construction | Steel Frame |
| Duty | Continuous |
| Enclosure Type | Open Dripproof |
| Frame Type | 184T |
| Insulation Type | Class F |
| KVA Code | J |
| Mounting Type | Rigid Base |
| Rotation | Counter-Clockwise |
| Start Method | Capacitor Start |
Performance Details
| Speed Rating | 1800 rpm |
| Full Load Efficiency | 75.5% |
| 1/2 Load Efficiency | 74.2% |
| Overload Protector | Manual |
| 3/4 Load Efficiency | 75.5% |
| Torque Rating | 9 lb-ft |
Electrical Properties
| Frequency Rating | 60 |
| Full Load Ampere | 16.9 A |
| Full Load Power Factor | 76% |
| 1/2 Load Power Factor | 71.3% |
| HP Rating | 3 HP |
| Phase | 1-Phase |
| Service Factor | 1.15 |
| 3/4 Load Power Factor | 73% |
Physical Properties
| Frame Size | 184 |
| Number of Poles | 4 |
| Shaft Diameter | 1.1245 Inch |
| Shaft Length | 2.75 Inch |
| Weight | 76 lb |
Environmental Condition
| Thermal Protection | Yes |
