SKF 3317 A/C3 Double Row Angular Contact Ball Bearing, 30 deg, 85 mm Bore x 180 mm OD x 73 mm W, Pressed Steel

The image shown is representative of the product family and may not specifically be the individual item.  SKF double row angular contact ball bearings correspond in design to two single row angular contact ball bearings arranged back-to-back, but take …

MFR #:229 GP

EIS #:3317A04

Series #:3300

UPC #:07316570747935

MFR #:229 GP

EIS #:3317A04

Series #:3300

UPC #:07316570747935

Out of Stock

Min Qty:1

  |

Qty Increment:1

WARNING: California Proposition 65 - Cancer and Reproductive Harm - www.P65Warnings.ca.gov
0
0
SKF double row angular contact ball bearings correspond in design to two single row angular contact ball bearings arranged back-to-back, but take up less axial space. They can accommodate radial loads as well as axial loads in both directions. They provide stiff bearing arrangements and are able to accommodate tilting moments. The standard assortment of SKF double row angular contact ball bearings comprises bearings in the 32 A, 33 A and 33 D series. Bearings in the 52 and 53 series are no longer available from SKF and have been replaced with 32 and 33 series bearings. With the exception of size 3200, 32 and 33 series bearings are dimensionally interchangeable with bearings in the 52 and 53 series. Size 3200 has a width of 14 mm instead of 14.3 mm. - SKF 3300 Double Row Angular Contact Ball Bearing.
$700.41 / Piece

Buy In Bulk & Save

1-24$700.41 / 1 Piece
25-49$589.45 / 1 Piece
50+$533.15 / 1 Piece

Buy In Bulk & Save

1-24$700.41 / 1 Piece
25-49$589.45 / 1 Piece
50+$533.15 / 1 Piece

Min Qty:1

  |

Qty Increment:1

WARNING: California Proposition 65 - Cancer and Reproductive Harm - www.P65Warnings.ca.gov
0
0
SKF double row angular contact ball bearings correspond in design to two single row angular contact ball bearings arranged back-to-back, but take up less axial space. They can accommodate radial loads as well as axial loads in both directions. They provide stiff bearing arrangements and are able to accommodate tilting moments. The standard assortment of SKF double row angular contact ball bearings comprises bearings in the 32 A, 33 A and 33 D series. Bearings in the 52 and 53 series are no longer available from SKF and have been replaced with 32 and 33 series bearings. With the exception of size 3200, 32 and 33 series bearings are dimensionally interchangeable with bearings in the 52 and 53 series. Size 3200 has a width of 14 mm instead of 14.3 mm. - SKF 3300 Double Row Angular Contact Ball Bearing.

Attributes

General Information
Item NameAngular Contact Ball Bearing
Series3300
Design & Construction
Cage MaterialPressed Steel
Enclosure TypeOpen
Performance Details
Contact Angle30 deg
Dynamic Load Capacity208000 N
Static Load Capacity176000 N
Tolerance ClassP6, P5
Physical Properties
Bore Diameter85 mm
Fillet Radius2.5 mm
Outside Diameter180 mm
Width73 mm
Environmental Condition
Temperature Rating120 °C
