Leeson MOTLM24789 Agricultural Duty Motor, 1/3 HP, 1800 rpm, 115V, 208 - 230V, 56 Frame, TEFC, Rigid Base Mount
EIS #:MOTLM24789
EIS #:MOTLM24789
In Stock
Min Qty:1
|Qty Increment:1
Leeson 230V 1-Phase Rigid Base Mount Totally Enclosed Fan-Cooled Enclosure Agricultural Duty Motor
Leeson 230V 1-Phase Rigid Base Mount Totally Enclosed Fan-Cooled Enclosure Agricultural Duty Motor. Gasketed capacitor cases and conduit box covers, Meets or exceeds NEMA service factors, Single phase and three phase designs, Double sealed ball bearings, Double shielded ball bearings on Ag fan motors
$572.97 / Piece
Min Qty:1
|Qty Increment:1
Leeson 230V 1-Phase Rigid Base Mount Totally Enclosed Fan-Cooled Enclosure Agricultural Duty Motor
Leeson 230V 1-Phase Rigid Base Mount Totally Enclosed Fan-Cooled Enclosure Agricultural Duty Motor. Gasketed capacitor cases and conduit box covers, Meets or exceeds NEMA service factors, Single phase and three phase designs, Double sealed ball bearings, Double shielded ball bearings on Ag fan motors
- Attributes
- Features
Attributes
General Information
Item NameAgricultural Duty Motor
Trade NameLeeson
General Features
Net Weight24 lb
StandardsUL Listed, CSA Certified
TypeSCS, High Torque, General Purpose
Design & Construction
Bearing TypeBall
ConstructionRolled Steel
DutyContinous
Enclosure TypeTotally Enclosed Fan-Cooled
Frame Type56
Insulation TypeClass B
KVA CodeN
Mounting TypeRigid Base
RotationSelective Counter-Clockwise
Shaft PositionHorizontal
Performance Details
Full Load Efficiency55%
1/2 Load Efficiency43.2%
Overload ProtectorManual
3/4 Load Efficiency50.5%
Torque Rating16 oz-ft
Electrical Properties
Frequency Rating60
Full Load Ampere6.6 A
Full Load Power Factor60%
1/2 Load Power Factor42.7%
HP Rating0.333 HP
Phase1-Phase
Service Factor1.15
3/4 Load Power Factor50%
Physical Properties
Dimensions12.82 Inch L x 8.34 Inch H
Frame Size56
Number of Poles4
Shaft Diameter0.625 Inch
Shaft Length2.32 Inch
Weight24 lb
Features
- Gasketed capacitor cases and conduit box covers
- Meets or exceeds NEMA service factors
- Single phase and three phase designs
- Double sealed ball bearings
- Double shielded ball bearings on Ag fan motors
- Condensate drains on general purpose Ag motors
- Low temperature manual overload protected
- High and extra high starting torque ratings
- 1-year warranty
- Voltage Rating: 115V, 208 - 230V
- Full Load Ampere: 6.6A at 115V, 3.1 - 3.3A at 208 - 230V
- Torque Rating: 16 oz-ft (Full Load)
