3M 2155 Temflex™ Vinyl Splicing Tape, 3/4" x 22 ' x 30 Mil, Black, MFR ID 7000089970
- MFR #7000089970
- EIS #3M2155X.75
- UPC #00051138979058
$9.71 / Roll
Available to Order
Min QTY1QTY Increment1more info
3M™ Temflex™ Splicing Tape 2155 with self fusing rubber backing, has rubber resin adhesive that offers optimized adherence. This tape is designed for low voltage electrical insulating and moisture sealing applications. It maintains the flexibility over a wide range of temperatures. Electrical insulating tape finds application in bolted connections, service drops, lightning connections, ground rod connections and motor leads. UL Listed and RoHS 2011/65/EU Compliant.
3M™ Temflex™ Tape 2155 is a 30 mil, general purpose, highly conformable, electrically insulating, low voltage rubber splicing tape. The self fusing tape is designed to offer guaranteed performance when used with solid dielectric cable insulations and has a liner, which will not stick to the tape upon unwind. It withstands a wide temperature range of 176 °F (80 °C).
Applications
- For Bolted Connections, Service Drops, Lightning Connections, Ground Rod Connections, Motor Leads
General Information
| Item Name | Splicing Tape |
| Trade Name | Temflex™ |
| Series | 2155 |
General Features
| Shelf Life | 36 Months |
| Storage Temperature | 70 °F |
Design & Construction
| Adhesive Type | Rubber |
| Backing Material | Vinyl |
| Color | Black |
Performance Details
| Tensile Strength | 300 psi |
Electrical Properties
| Dielectric Strength | 600 V/mil |
Physical Properties
| Core Size | 3 Inch |
| Elongation | 700% |
| Length | 22 ft |
| Thickness | 30 mil |
| Width | 0.75 Inch |
Environmental Condition
| Temperature Rating | 176 °F |
