3M DMD 180 Triplex High Performance Flexible Laminate Roll, MFR ID Dacron® Mylar® Dacron®-180-ROL
- MFR #Dacron® Mylar® Dacron®-180-ROL
- EIS #PH21-Dacron Mylar Dacron-180-ROL
- Series #Dacron® Mylar® Dacron®-180-ROL
$15.64 - $27.92
Refine your product below or compare all choices in the
Min QTY1QTY Increment1more infoPack--
| Stock Status | |||||
|---|---|---|---|---|---|
 | 300 Yard | 11 mil | 3.375 Inch | $ / Square YD | |
| 36 Yard | 20 mil | 36 Inch | $ / Square YD | |
| 36 Yard | 15 mil | 36 Inch | $ / Square YD | |
 | 36 Yard | 9 mil | 36 Inch | $ / Square YD |
3M DMD 180 Triplex High Performance Flexible Laminate. - 3M™ DMD180 High-Performance Flexible Laminate is a specially formulated non-woven material laminated on both sides of a polyester film.
Features
- Flexible
- Conformable
- High tensile strength
- Excellent tear resistance
- Low moisture absorption
- High thermal conductivity
- Long term voltage endurance
- Resistance to partial discharge (corona)
- High mechanical strength
- Well suited for automatic insertion applications and heavy-duty winding applications
Applications
- Primarily Used in Motor Repair Applications and High-Temperature Electrical Insulation Applications
- Motors
- Generators
- Slot Liners
- Phase Insulation
- Well-Suited for Automatic Insertion Applications and Heavy-Duty Winding Applications
- Compatible with commonly used impregnating resins and varnishes
General Information
| Item Name | High Performance Flexible Laminate |
| Trade Name | Dacron® Mylar® Dacron®-180 |
| Series | Dacron® Mylar® Dacron®-180-ROL |
General Features
| Type | Triplex |
Design & Construction
| Insulation Type | Class H |
Performance Details
| Moisture Absorption | <1% |
